This doypack bag making machine which apply to laminated film bags making by inner heating sealing with friendly PLC control systems . And the folding pattern is in horizontal unwinding for adjusting the vertical lifting triangular device, folded by A-shape framework and film supplied basis.
Technical Parameter
| Model | HL0600A3 | Power | 50kw/380v | Gross Weight | 6500kg |
| System | PLC | Control | Screen | Overall Dimension | 12500X2300X1900mm |
| Voltage of Main Motor | 3kw | Voltage of traction motor | 1.5kwX3=4.5kw | Voltage of Unwinding motol | 0.55kw |
| Voltage of assitant Motor | 0.4kwX2=0.8kw | Voltage of horizontal sealing | 2kwX8=16kw | Voltage of vertical sealing | 2kwX8=16kw |
| Voltage of Zipper | 2kwX4=8kw | Tension Control | Automatic | Feeding | Cylinder |
| Application of bags | 3-side sealing bags | Stand-up bags | 3-side sealing Zipper bags | Stand-up Zipper bags | 4-side sealing bags |
| Speed | 150pcs/min | 120pcs/min | 140pcs/min | 140pcs/min | 80pcs/min |
| Specification(No use times feeding) | Width :80-600mm | Width :50-350mm | Width :50-400mm | Width :50-400mm | Width :80-500mm |
| Length:30-400mm | Length:150-500mm | Length:150-600mm | Length:150-500mm | Length:30-400mm | |
| Optional Function | 1.Double Unwinding 2.Main Servo-motor Control 3.Double Cutting-knife 4.Incessant Unwinding without stop the machine 5.0ptional Model Specification:400/500 | ||||
Application of material:
BOPP/CPP ; BOPP/CPE ; BOPP/PET/PE ; BOPP/PET/CPP ; PET/PE ; PET/CPP ; PET/AL/PE ; PET/AL/NY/PE ; NY/PE ; PET/PAPER/AL/PE of composite material and so on
Service guarantee
After the equipment debugging is qualified, we will provide comprehensive value-added services to ensure smooth production for customers. Provide exclusive operation training for customers, detailing the optimal operating parameters, operating procedures, daily maintenance skills, and common troubleshooting methods after equipment debugging; Equipped with complete debugging materials and technical manuals, including debugging plans, parameter setting tables, testing reports, etc., for customers to easily refer to and consult in the future; Establish an after-sales tracking mechanism, conduct follow-up visits to customers within 72 hours after equipment delivery to understand the operation status of the equipment, answer customers' questions about parameter optimization and operation, and if necessary, dispatch engineers to assist customers in on-site debugging and adaptation, fully ensuring the smooth development of customer production.
We always take "customer needs as the guide, quality assurance as the core", and provide refined and comprehensive equipment debugging services to ensure that every soft plastic packaging machinery can accurately match customer production needs, helping customers improve production efficiency, reduce production costs, and achieve mutual benefit and win-win results.
FAQ
Q: Why choose me as the bag making machine supplier?
A: More than 33 years experienced in manufacturing bag making machine & accessoires, we adhere to the policy of self-production and self-use. Our machines are directly applied to our own company's production, ensuring continuous feedback for equipment updates and optimizations, and achieving a combination of practical application and production.
Q2: Can Tianzheng bag-making machine be designed directionally on demand?
A: With years of experience in bag production, Tianzheng has mastered the bag-making process. We can meet customers' special requirements (such as oversized bags, online shape bag die-cutting, and added spouts...) to achieve production standards, fulfill non-standard customized orders, and perfectly align with customer production requirements.
Q3: What about the after-sales service of Tianzheng bag-making machines? Will there be no after-sales support after purchasing a Tianzheng bag-making machine?
A3: First and foremost, quality is the core of Tianzheng bag-making machines. Prioritizing machine quality aligns better with customers' purchasing criteria than focusing solely on after-sales service. Secondly, we guarantee a 24-month warranty period for all Tianzheng bag-making machines. We also commit to providing 365-day round-the-clock after-sales service, with 7/24 online consultation to resolve after-sales issues promptly. We make the utmost commitment to ensuring our customers have access to high-performance equipment.
